Description:
3" Swivel Caster with Top Plate
Features:
- Zinc-plated finish is attractive and durable
- Full double ball hardened raceways for better performance and greater durability
- 3/8" hollow axle with lock nut
- Permanent rivet kingpin construction
- Reinforcing washer on upper and lower raceways
- Grease hole on wheel bearing
- Multi-temp grease lubricates in extreme hot and cold temperatures
- 5/32" thick steel top plate
- Performa rubber rolls easily, quietly, protects floors and resists impacts with a cushioned ride and features maximum weather-ability, low temperature flexibility, resistance to chemicals, water and steam, and rejects floor debris such as metal shavings
Specifications:
- Diameter: 3"
- Tread Width: 1-1/2"
- Tread Material: Performa Rubber (Flat)
- Top Plate Dimensions: 3-3/4" x 4-3/8"
- Bolt Hole Spacing: 2-5/8" x 3"
- Bolt Diameter: 3/8"
- Bearing: Roller
- Load Height: 4-1/2"
- Swivel Radius: 3-1/8"
- Weight Capacity: 250 lbs.
- For California residents only:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ACTUAL PRODUCT & COLORS MAY VARY FROM WHAT IS SHOWN
